MONITOR AUDIO BRONZE SERIES – MADE FOR YOU
Monitor Audio officially launched the 6th generation of its award-winning Bronze Series of loudspeakers. The new speakers have received a complete upgrade in both sound and build quality to give a performance to remember.
The Bronze Series features a new Uniform Dispersion Waveguide which combines with Monitor Audio’s signature C-CAM Gold Dome Tweeter to give even sound dispersion, improved time alignment and wider directivity for a more lifelike listening experience.
The unique, acoustically transparent hexagonal dispersion patterns on the tweeter covers give Bronze a premium feel and allow light to catch the distinctive gold tweeter domes behind the grilles. Gold-plated terminals and Pureflow silver-plated oxygen-free copper internal cabling offer secure cable connectivity.
The fresh cabinet designs have clean and simple lines and are available in a choice of four contemporary finishes. Sleek contrasting baffles and matching magnetic cloth-covered grilles provide an understated appearance.
Since its first launch two decades ago, the multi award-winning Bronze Series has set the standard as a class leader and today there are thousands of satisfied owners across the globe.
With a choice of eight models, including Monitor Audio’s first Dolby Atmos® enabled module, the Bronze Series has been designed to please any music or movie lover. The attractive styling and choice of finishes ensure that the speakers will complement any room in the home.
Key Features
Superior in build quality and sound
Designed for your home, with clean lines to suit both classic and contemporary home décor
Performance led – intricately engineered to optimise the audio experience
Monitor Audio signature C-CAM Gold Dome Tweeter featuring new Uniform Dispersion (UD) Waveguide
Monitor Audio C-CAM Mid-Bass Drivers featuring new Damped Concentric Mode (DCM) technology which works in partnership with UD Waveguide to lower the crossover frequency
The Monitor Audio family look with acoustically transparent hexagonal dispersion pattern on the tweeter plate
Rear ported and tuned for ease of positioning without affecting sound performance
Two dedicated cinema speakers, Bronze FX and new Bronze AMS Dolby Atmos® enabled upward-firing speakers to add a new dimension to movie soundtracks
New Bronze AMS Dolby Atmos® enabled speakers
5 year Warranty
Choice of four high-quality contemporary finishes – White, Walnut, Urban Grey and Black
Finishes
Black – black vinyl and satin dark grey front baffle
White – white vinyl and satin light grey front baffle
Walnut – walnut wood vinyl and satin dark grey front baffle
Urban Grey – grey wood vinyl and satin light grey front baffle
Bronze Series Specifications
Model | Bronze 50 | Bronze 100 | Bronze 200 | Bronze 500 | Bronze C150 | Bronze FX | Bronze AMS Dolby Atmos® Enabled Speaker |
System Format | 2-way | 2-way | 2.5-way | 2.5-way | 2-way | 2-way | 2-way |
Frequency response (-6dB) Free field In room | 62 Hz – 25 kHz 40 Hz – 30 kHz | 52 Hz – 25 kHz 37 Hz – 30 kHz | 45 Hz – 25 kHz 35 Hz – 30 kHz | 41 Hz – 25 kHz 32 Hz – 30 kHz | 83 Hz – 25 kHz 66 Hz – 30 kHz | 88 Hz – 25 kHz 74 Hz – 30 kHz | 120 Hz – 25 kHz 105 Hz – 30 kHz |
Sensitivity (2.83v @ 1m) | 85 dB | 87 dB | 88 dB | 90 dB | 88 dB | 86 dB | 86 dB |
Nominal impedance | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms |
Minimum Impedance | 4.4 Ohms | 4.5 Ohms | 4.4 Ohms | 4.1 Ohms | 4.3 Ohms | 4 Ohms | 4 Ohms |
Maximum SPL | 107 dBA (pair) | 110 dBA (pair) | 112 dBA (pair) | 116 dBA (pair) | 109 dBA (each) | 108 dBA (pair) | 107 dBA (pair) |
Power Handling (RMS) | 80 W | 100 W | 120 W | 200 W | 120 W | 80 W | 60 W |
Recommended Amplifier Requirements | 20 – 80 W | 30 – 100 W | 40 – 120 W | 60 – 200 W | 30 – 120 W | 20 – 80 W | 10 – 60 W |
Bass Alignment | Bass reflex HiVe II port system | Bass reflex HiVe II port system | Bass reflex Dual HiVe II port system | Bass reflex Dual HiVe II port system | Sealed cabinet | Sealed cabinet | Sealed cabinet |
Crossover Frequency | 2,5 kHz | 2,2 kHz | 700 Hz 2,4 kHz | 550 Hz 2,7 kHz | 2,7 kHz | 2,8 kHz | 2,5 kHz |
Drive Unit Complement | 1 x 51/2” C-CAM mid-bass driver 1 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide | 1 x 8” C-CAM mid-bass driver 1 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide | 2 x 51/2” C-CAM mid-bass driver 1 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide | 2 x 8” C-CAM mid-bass driver 1 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide | 2 x 51/2” C-CAM mid-bass driver 1 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide | 1 x 51/2” C-CAM mid-bass driver 2 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide | 1 x 4” C-CAM mid-bass driver 1 x 25 mm C-CAM Gold Dome tweeter with optimised Waveguide* |
External Dimensions including Grille and Terminals (H x W x D) | 281 x 166 x 265 mm 111/16 x 69/16 x 107/16” | 376 x 231 x 325 mm 1413/16 x 91/8 x 1213/16” | 886 x 166 x 265 mm 347/8 x 69/16 x 107/16” | 951 x 231 x 325 mm 377/16 x 91/8 x 1213/16” | 166 x 451 x 225 mm 69/16 x 173/4 x 88/16” | 287 x 284 x 124 mm 115/16 x 113/16 x 47/8” | 152 x 166 x 242 mm 6 x 69/16 x 91/2” |
External Dimensions including Outrigger Feet and Spikes (H x W x D) | N/A | N/A | 909 x 229 x 304 mm 3513/16 x 9 x 1115/16” | 974 x 294 x 364 mm 383/8 x 119/16 x 145/16” | N/A | N/A | N/A |
Weight (Each) | 5.0 kg 11 lb | 7.8 kg 17 lb 3 oz | 12.8 kg 28 lb 4 oz | 18.0 kg 39 lb 11 oz | 7.0 kg 15 lb 7 oz | 3.9 kg 8 lb 10 oz | 2.5 kg 5 lb 8 oz |
Finishes | Black, White, Walnut, Urban Grey | Black, White | Black, White |
Bronze W10 Subwoofer Specifications
Model | Bronze W10 Subwoofer |
System Format | Long-throw 10” driver featuring ‘dished’ C-CAM cone. 10” flat panel ABR (Auxiliary Bass Radiator). 18 mm MDF internally braced construction |
Lower Frequency Limit | -3 dB @ 33 Hz / -10 dB @ 28 Hz (Free Field) Default preset: Music, -3 dB @ 29 Hz / -10 dB @ 25 Hz (In room) |
Upper Frequency Limit | -6 dB @ 150 Hz |
Drive Unit Complement | 1 x 250 mm (10”) C-CAM subwoofer driver featuring a 2” long throw voice coil |
Linear Driver Excursion | 17 mm peak to peak |
Amplifier Output | 220 W |
Amplifier Classification | Class D with high current Switch mode power supply (SMPSU) |
Phase Control | 0 Degrees & 180 Degree pure Invert |
Low Pass Filter Alignment | 2nd order (12 dB/Octave), from 40 Hz to 120 Hz |
Equalisation DSP | 3 pre-set modes: Music, Movie, Impact |
Auto Sensing | Line Level >3mV. Auto Standby feature after 20 mins |
Audio Inputs | LFE unbalanced input RCA Stereo unbalanced inputs RCA |
Input Impedance | 20 kOhms input impedance |
12 V Trigger | 3.5 mm mono mini-jack. 6 V threshold |
Electrical Certifications | CE / CB / ETL / Fcc / CCC / ErP (Energy saving compliant) |
Mains Input Voltage | 100 – 120 VAC ~60Hz / 220 – 240 VAC ~50/60 Hz (Manually selected) |
Power Consumption | Maximum 300 W, Standby <0.5 W (ErP compliance) |
Fuse Type | 20 mm T4AL 250 VAC |
External Dimensions including Amp, Drivers & Terminals (H x W x D) | 321 x 321 x 364 mm 125/8 x 125/8 x 145/16“ |
External Dimensions including Amp, Drivers, Terminals & Feet (H x W x D) | 366.5 x 321 x 364 mm 147/16 x 125/8 x 145/16“ |
Weight (Unpacked) | 13.4 kg / 29 lb 9 oz |
Finishes | Black, White, Walnut, Urban Grey |
For more information email [email protected]
Additional technical details are available at www.monitoraudio.com
Monitor Audio is a wholly British owned and managed loudspeaker designer and manufacturer. Since 1972 it has been at the leading edge of loudspeaker design and technology, perfecting the implementation of metal drivers. It is renowned for exemplary speaker cabinet construction and finish.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Atmos, and the double-D symbol are trademarks of Dolby Laboratories.
